TRAINER push station with folding seat for mixed outdoor use
2,442.00 € excl. VAT
Outdoor chest press station with a folding seat for wheelchair and standing users, 1140 x 740 x 2020 mm. Certified to EN 16630:2015-06 by TUV Rheinland.
Priced quotation within 24 business hours. No commitment. Our commitments
Description
The TRAINER push station with pylon works the chest, the scapular girdle and the upper limbs through a pressing movement, and its folding seat adapts instantly to a wheelchair user or to a standing user. Paired with the pulling station in the same range, it gives a balanced upper body circuit on two pieces of outdoor equipment.
Construction follows the range: high quality steel, shot blasted then galvanised, with a double coat of polyester paint, and a seat in high density polyethylene panels. The unit weighs 50 kg and the mounting pylon, included, adds 50 kg.
Overall dimensions are 1140 x 740 x 2020 mm and the recommended safety zone is 414 x 374 cm, slightly wider than the pulling station because of the longer press travel. Maximum user weight is 150 kg, the difficulty level is medium, and the equipment is certified to EN 16630:2015-06 by TUV Rheinland.
Technical specification
| Function | Pressing movement: chest, scapular girdle, upper limbs |
| Accessibility | Folding seat, wheelchair users and standing users |
| Structure | Shot blasted and galvanised steel, double polyester paint coat |
| Seat | High density polyethylene panels |
| Weight | 50 kg plus 50 kg mounting pylon included |
| Overall dimensions | 1140 x 740 x 2020 mm |
| Safety zone | 414 x 374 cm |
| Maximum user weight | 150 kg |
| Difficulty level | Medium |
| Standard | EN 16630:2015-06, tested and certified by TUV Rheinland |
| Colours | Yellow RAL 1018/7004, graphite RAL 7016/9006, orange RAL 2000/9006, lime RAL 6018/9006; others on quotation |
| Reference | D01R+SI+SLW2 |
| Price | 2,442 EUR excluding VAT |
Laying out an inclusive outdoor circuit
Push and pull stations are normally installed as a pair, with three to four metres between them so that the two safety zones do not overlap and a wheelchair can turn between them. Adding a mobility station and a cardio station completes a circuit that a user can run through in fifteen minutes.
The surfacing is the decisive item of the budget on an inclusive project. A firm, level, non slip surface across the safety zones and along the approach routes costs more than grass, and it is the condition without which the accessible equipment cannot be reached.
Frequently asked questions
Why is the safety zone larger than on the pulling station?
The pressing movement extends further from the frame, so the recommended zone is 414 x 374 cm against 394 x 374 cm for the pulling station.
Can a standing user use the same station?
Yes. The seat folds down for standing users and folds away for a wheelchair, with no tools and no intervention by an attendant.
What is the lead time?
Dispatch from stock is typically 5 to 10 working days. Confirm availability with your quotation, which is issued within 24 working hours.
Request a quotation for a reply within 24 working hours, or browse the accessible outdoor gym equipment range.
Additional information
| Weight | 50 kg |
|---|---|
| Dimensions | 114 × 74 × 202 cm |
