TRAINER butterfly, pylon mounted outdoor chest station

The TRAINER Butterfly is a pylon mounted outdoor chest press station weighing 47 kg, certified to EN 16630:2015 and tested by TUV Rheinland. The arms close in front of the chest against the user body weight and lever geometry, loading the pectorals, the anterior deltoid and the scapular girdle. Because the unit bolts onto a support pylon or a load bearing wall rather than onto its own ground frame, it fits narrow park corridors, promenade walls and compact municipal fitness areas where a free standing machine would not.

Technical specification

Pylon mounting and what it changes for the site

OutdoorFit stations are designed around a shared support post. One pylon carries the station and transfers the load into a single concrete foundation, which reduces excavation compared with a free standing frame and allows two devices to be paired back to back on the same post when the layout allows it. The quoted price covers the station itself; the pylon or load bearing wall fixing is required for installation and is priced separately, so budget for it at specification stage rather than at delivery.

• Chest, front shoulder and scapular girdle in one guided movement
• Body weight resistance, no stack to maintain or vandalise
• Compact 101 x 101 cm envelope, suitable for linear park layouts
• Moderate difficulty, adults and teenagers from 140 cm
• Same colour palette as the rest of the TRAINER range for a coherent park identity

Corrosion protection and inspection duties

The steel is shot blasted and hot dip galvanised before the two coat polyester finish is applied. Protection therefore sits in the zinc layer under the paint, so a scratch from a bicycle handlebar or a skateboard does not open a corrosion path. This is the standard construction across the TRAINER outdoor line and is the reason the equipment is specified for coastal and heavily used urban sites.

The 400.9 x 385 cm safety area must be kept clear of obstacles and surfaced according to the free height of fall stated in the installation drawing. Once commissioned, the operator carries the usual duties for publicly accessible outdoor fitness equipment: routine visual checks, a periodic operational inspection of moving joints and fixings, and an annual main inspection recorded in the site log.

Frequently asked questions

Is the support pylon included in the price?

No. The 1,926 EUR excluding VAT figure covers the butterfly station. The pylon, which adds around 50 kg, and its foundation are quoted separately along with delivery and installation.

How is the resistance adjusted?

There is no weight stack. Resistance comes from the user body weight acting through the lever geometry, so effort is regulated by tempo, range and repetition count. That is deliberate for unsupervised public installation, where selector pins and cables would be a maintenance and vandalism liability.

Which station pairs best with it?

The reverse butterfly from the same range, which trains the opposing muscle group. Installing both on adjacent pylons gives balanced pushing and pulling work for the shoulder girdle within one compact zone.
