Rope play configuration no. 36 - pyramid with double and triple slides
Rope play configuration no. 36 - pyramid with double and triple slides : combined rope play structures for playgrounds, marque Light In Fitness, tarif sur devis. Delivery and installation priced on quotation across Europe.
Price on request
Five-component configuration pairing a play structure with a rope pyramid, a double slide and an additional triple slide.
Price on request – project quotation within 24 business hours.
This item is supplied on quotation: configuration, delivery and installation are priced against your project.
Request a quotation +33 6 20 72 66 96
Answer within 24 to 72 business hours, quote reference LIF-KZ36-1136. Layout study, delivery, installation and after sales.
Description
Configuration 36 is the entry point to the large configurations. Five components, a play structure, a transition passage, a rope play pyramid with a double slide and an additional triple slide, occupy 23.2 x 19.0 m and rise to 7.0 m, needing a reserved zone of 27.0 x 23.3 m.
Components
- A play structure
- A rope play pyramid
- A double slide
- An additional triple slide
- A transition passage between the two units
Stepping up from a single structure
Many clients arrive at a configuration after a single structure has proved too small. The step is significant: from a reserved area under 200 square metres to more than 600, from one set of foundations to several, and from a modest surfacing package to one that will dominate the groundworks budget. Configuration 36 is the smallest of the multi-unit layouts, so it is usually where that transition is best tested.
Site and installation
Free height of fall 3.0 m, foundations at 1.0 m depth, and heavy construction plant access required. Both slides need clear run-outs inside the reserved zone.
Materials
Hot-dip galvanised and powder-coated steel structure.
Technical specification
| Reference (SKU) | LIF-KZ36-1136 |
|---|---|
| Overall dimensions | 23.2 x 19.0 x 7.0 m (L x W x H) |
| Minimum safety area | 27.0 x 23.3 m |
| Age range | 5 to 14 years |
| Free height of fall | 3.0 m |
| Foundation depth | 1.0 m |
| Frame | Hot-dip galvanised steel |
| Finish | Powder coated over galvanising |
| Standard | EN 1176-1:2017, certified by an independent body |
| Price | On request – project quotation within 24 business hours |
Documentation supplied
Every configuration is delivered with the certificate of conformity from the independent certification body, the technical data sheet, the installation and maintenance manual and a site layout drawing showing the reserved zone. Public buyers can attach that file directly to a tender return.
Frequently asked questions
Is a configuration better value than two separate structures?
Generally yes, because the linked units share safety zones and a single mobilisation covers all the foundations. Two independent structures each need their own clear area, which increases the total surfacing bill.
Why a double slide and a triple slide?
Side-by-side slides turn descent into a shared activity rather than a queue, and they clear the upper levels quickly, which matters when a configuration this size fills up at a weekend.
What is the smallest plot that will take it?
27.0 x 23.3 m of clear ground. Below that, a single large pyramid such as CALIBAN or a Diamond Collection structure will give better value than a compromised configuration.
Send us the plot dimensions and we will tell you whether a configuration or a single structure is the better answer. Browse the complex playground configurations range or request a quote.
