Namaka Crossed Beam Double Swing
Namaka Crossed Beam Double Swing : playground swing sets and inclusive swing seats, marque Light In Fitness, tarif sur devis. Namaka – Balançoire Double CroiséeNamaka associe deux balançoires dont les poutres principales sont disposées à angle droit, formant une silhouette originale et compacte. Delivery and installation priced on quotation across Europe.
Price on request
Price on request — project quotation within 24 business hours.
Double swing with beams at right angles in hot-dip galvanised S235 steel, with ROSTA dampers.
This item is supplied on quotation: configuration, delivery and installation are priced against your project.
Request a quotation +33 6 20 72 66 96
Answer within 24 to 72 business hours, quote reference LIF-NAMAKA-609. Layout study, delivery, installation and after sales.
Description
Namaka sets its two main beams at right angles to each other, so a double swing occupies a square plot instead of a long strip. The columns are 168.3 mm S235 carbon steel tube, hot-dip galvanised, and the beams are 120 x 120 mm square section fitted with ROSTA dampers and rubber buffers.
Why the crossed layout matters
Standard swing bays force a long, narrow safety area, which is often the reason a swing cannot be fitted into an existing park corner. By turning one bay through ninety degrees, Namaka spreads the requirement into a 10.5 x 10.1 m square. On a site bounded by a path on one side and a hedge on the other, that is frequently the difference between a swing and no swing.
- Main beams in 120 x 120 mm square tube
- Columns in 168.3 mm diameter S235 carbon steel tube, hot-dip galvanised
- ROSTA dampers and rubber buffers limiting beam oscillation
- Rubber seats suspended on stainless steel chains
- Seats mounted at 2.3 m and 2.8 m
- Reinforced concrete footings
Technical specification
| Reference | LIF-NAMAKA-609 |
|---|---|
| Dimensions | 5.4 x 5.1 x 3.0 m (L x W x H) |
| Age range | 3 to 14 years |
| Free height of fall | 2.0 m |
| Safety area | 10.5 x 10.1 m minimum |
| Foundation depth | 1.0 m, reinforced concrete footings |
| Frame | S235 carbon steel, hot-dip galvanised |
| Seat suspension | Stainless steel chains, rubber seats |
| Seat heights | 2.3 m and 2.8 m |
| Standard | Certified to EN 1176 by an independent certification body |
| Price | On request — project quotation within 24 business hours |
Installation
Foundations are 1.0 m deep reinforced concrete footings, deeper than the stainless steel swing frames in the range because of the beam geometry and the loads it transfers. Plan for machine excavation and confirm the position of any buried services under the four column positions before setting out.
Maintenance
The dampers are the distinctive component: they absorb the beam oscillation that would otherwise be transmitted into the columns and the foundations, and their condition should be recorded at the annual inspection. Galvanised steel needs no repainting in normal conditions. The rest follows the routine, operational and annual regime required by EN 1176.
Frequently asked questions
Why are the two seat heights different?
The 2.3 m and 2.8 m suspension heights give two different swing characteristics on one structure, so older and younger children in the 3 to 14 range each get a bay that suits them.
Is galvanised steel as durable as stainless?
Hot-dip galvanising gives long service in inland conditions and is the usual specification for heavy swing frames. In severe coastal exposure we would discuss a stainless frame from the same range instead.
Can the safety areas of the two bays overlap?
They are already designed as a single combined area of 10.5 x 10.1 m. That figure must be surfaced and kept clear in full.
Send us the corner you are trying to fill and we will check the geometry. Request a quotation or see the full playground swing sets range.
