Gold Line 45 Degree Leg Press - Plate-Loaded Leg Machine
1,615.00 € excl. VAT
Gold Line 45 degree leg press: plate-loaded inclined sled, Olympic 50 mm posts, safety bar. 165 x 105 x 116 cm, 240 kg, users to 180 kg. 1,615 EUR excluding VAT.
Priced quotation within 24 business hours. No commitment. Our commitments
Description
The Gold Line 45 Degree Leg Press is a plate-loaded inclined leg press for intensive lower-body training. It measures 165 x 105 x 116 cm, weighs 240 kg and accepts users up to 180 kg. Light In Fitness supplies it at 1,615 EUR excluding VAT.
The angle that lets people load properly
At 45 degrees the sled travels along a diagonal, so a portion of the load is carried by the rails rather than by the athlete. That is precisely why the inclined press produces the highest absolute loads of any leg movement on a gym floor, and why members who will never approach a heavy squat will happily press two or three times their body weight here. The movement drives the quadriceps, the glutes and the hamstrings through a controlled range, with the back supported throughout.
- 45 degree inclined sled, plate-loaded on Olympic 50 mm posts, two loading levels
- Non-slip foot platform
- Safety bar limiting the working range
- Quick-release seat adjustment, settings marked in yellow
Inclined or vertical: choosing between the two presses
The vertical press in the same range takes about half the floor area and biases the glutes and hamstrings more heavily because of the longer hip range. The 45 degree press takes more room but supports the back through the whole movement, is easier to enter and leave, and allows far heavier absolute loads. Clubs with space install both; clubs choosing one usually take the 45 degree version, because it is the machine members recognise and ask for.
Construction
Hot-rolled SPHC oval steel tube, 3 mm wall, laser cut and robot welded, on non-slip rubber floor supports. Grip zones are extra-strength TPR-EVA. The seat uses a twin pneumatic cylinder reinforced construction with 2 mm upholstery leather over high-density polyurethane foam. Finish is a powder coating applied as two protective base coats plus a final top coat, black or grey as standard, with custom colours available.
Specification
| Reference / SKU | LIF-17465, Gold Line plate loaded |
|---|---|
| Type | 45 degree inclined leg press, plate loaded |
| Dimensions | 165 x 105 x 116 cm (L x W x H) |
| Weight | 240 kg |
| Maximum user weight | 180 kg |
| Plate fitting | Olympic 50 mm posts, two loading levels |
| Frame | SPHC hot-rolled oval steel tube, 3 mm wall |
| Finish | Powder coating, two base coats plus top coat; black or grey standard |
| Upholstery | 2 mm leather over high-density PU foam, TPR-EVA grips |
| Price | 1,615 EUR excluding VAT |
Olympic plates are quoted separately. At 240 kg unloaded, check the floor loading before installing above ground level.
Frequently asked questions
How many plates should be provided for a leg press?
More than for any other station. A club should plan on at least 200 kg of 50 mm plates dedicated to the leg press area, kept on the machine posts and on a nearby tree so that loading does not empty the rest of the free-weight zone.
What is the safety bar for?
It limits how far the sled descends, which stops the hips rolling under and the lower back rounding at the bottom of the range. Set it during induction for each user population; it is the single most useful safety adjustment on the machine.
Does it need to be anchored?
No. At 240 kg unloaded and considerably more in use, the machine is stable on its rubber floor supports. Anchoring is only considered on sloping or unusually slippery floors.
Light In Fitness supplies the Gold Line plate-loaded series and complete strength floors to clubs, hotels, corporate gyms and armed forces facilities across France and Europe. Browse the plate-loaded machines range or the plates and bumpers catalogue. Send us your floor plan and we return a machine list, a layout and a project price.
