Rope play configuration no. 41 - twin pyramids with wide and tube slides

In brief — Rope play configuration no. 41: dimensions 1840 × 1450 × 450 cm, material hot-dip galvanised and powder-coated steel, free fall height 1,0 m, age range 5 to 14 years, standards EN 1176-1:2017, certification certificate of conformity from an independent certification body, price on quotation.

Configuration 41 brings five integrated components together: two rope play pyramids, a wide slide, a transition bridge between them and an additional tube slide. Across 18.4 x 14.5 m it delivers the play value of a large scheme while holding the free height of fall to 1.0 m, which is the lowest figure of any configuration at this size.

Components

• Two rope play pyramids
• A wide slide
• An additional tube slide
• A transition bridge linking the two pyramids

Why the low fall height matters here

Most configurations of this footprint carry a 3.0 m free height of fall, which drives a deep and expensive impact surface across the whole reserved zone. At 1.0 m, configuration 41 needs a far shallower build-up over its 21.8 x 16.1 m zone. On a scheme where the surfacing was going to be the deciding cost, that single figure often makes the difference.

Surfacing and groundworks

Impact-attenuating surfacing tested to EN 1177 is mandatory beneath the fall area. Foundations are cast at 1.0 m depth. The wide slide and the tube slide each need a clear run-out inside the reserved zone, so orientation is fixed at layout stage.

Materials

Hot-dip galvanised and powder-coated steel structure.

Technical specification

Comparing costs honestly

When you compare configurations, compare reserved areas and fall heights, not equipment prices alone. A layout with a 1.0 m fall height across 21.8 x 16.1 m can be markedly cheaper to complete than a nominally similar configuration at 3.0 m, once the impact surface is included in the total.

Frequently asked questions

Why link two pyramids rather than install them separately?

A transition bridge turns two structures into one circuit. Children cross between them instead of climbing down and walking across, which keeps them inside a single supervised envelope and roughly doubles the number of possible routes.

How does configuration 41 differ from configuration 39?

They occupy the same 18.4 x 14.5 m plan and the same 21.8 x 16.1 m zone. Configuration 39 uses three pyramids and two connectors; configuration 41 uses two pyramids, one bridge and an additional tube slide.

Can the powder coat colours be specified?

Yes, the steel is powder coated over the galvanising, so a scheme colour can be agreed at order stage.

Send us the plot dimensions and your colour scheme and we will return a costed layout. Browse the complex playground configurations range or request a quote.
