PHOBOS XL 4 m rope climbing pyramid
PHOBOS XL 4 m rope climbing pyramid : rope climbing pyramids for playgrounds, marque Light In Fitness, tarif sur devis. PHOBOS XL – Pyramide de jeu en corde 4 mLa pyramide PHOBOS XL propose une plateforme de jeu unique perchée à 2,5 m, offrant une expérience d'escalade dynamique dans une emprise au sol réduite. Delivery and installation priced on quotation across Europe.
Price on request
Four-metre climbing pyramid with a single rope platform perched at 2.5 m, a dramatic profile on a moderate footprint.
Price on request – project quotation within 24 business hours.
This item is supplied on quotation: configuration, delivery and installation are priced against your project.
Request a quotation +33 6 20 72 66 96
Answer within 24 to 72 business hours, quote reference LIF-PHOBOSXL-201. Layout study, delivery, installation and after sales.
Description
PHOBOS XL puts one rope platform at 2.5 m under a 4 m mast. There are no intermediate stages, so the climb is continuous and the arrival feels earned. For a park that wants a visible landmark without committing to a 6 or 7 m pyramid, this is the point where height starts to read from a distance.
Configuration
- Central hot-dip galvanised steel mast, 168.3 mm diameter, 4 m high
- Six main cables anchored into reinforced concrete footings
- Six rope walls between the bearing cables
- A single rope platform at 2.5 m
- Hot-dip galvanised adjustment bolts at the anchors
Site and installation
The safety area is a 10.5 m diameter circle, 86.5 square metres, and foundations are cast at 0.8 m depth. Light to moderate plant access may be required for erection, so it is worth confirming gate widths and ground bearing before the programme is fixed. Where access is genuinely restricted, the 3 m PHOBOS delivers the same single-platform concept within a 9.0 m circle.
Materials
Hot-dip galvanised steel mast, 168.3 mm diameter. Polyamide cables reinforced with galvanised steel, 18 mm diameter. Plastic and aluminium connectors; stainless steel and painted cast steel fixings.
Technical specification
| Reference (SKU) | LIF-PHOBOSXL-201 |
|---|---|
| Overall dimensions | 7.5 x 7.5 x 4.0 m (L x W x H) |
| Minimum safety area | 10.5 m diameter circle (86.5 m²) |
| Age range | 5 to 14 years |
| Free height of fall | 2.5 m |
| Foundation depth | 0.8 m |
| Frame | Hot-dip galvanised steel mast, 168.3 mm diameter |
| Finish | Hot-dip galvanised; 18 mm steel-reinforced polyamide cable |
| Standard | EN 1176-1 |
| Price | On request – project quotation within 24 business hours |
Frequently asked questions
What surfacing depth does a 2.5 m fall height require?
More than the low pyramids in the range, and it must extend across the whole 10.5 m circle. Bonded rubber thickness or loose-fill depth is selected against the 2.5 m figure; we can price the surfacing with the equipment so the two are never mismatched.
Is a continuous climb suitable for younger children?
The approval starts at 5 years for this reason. Without intermediate platforms there is no natural resting stage, so the unit suits confident school-age climbers rather than early years.
What plant is needed on site?
Light to moderate machinery access may be required for installation. Send us a photograph of the access route and the working area and we will confirm the requirement before quoting.
Tell us the clear diameter available and your age profile and we will confirm the fit. Browse the rope climbing pyramids range or request a quote.
