Double Eight - Twin-Loop Structure with Rope Tunnels

In brief — Double Eight – Twin-Loop Structure with Rope Tunnels: free fall height 3,0 m, age range 5 to 14 years, safety area 14,9 x 7,5 m, standards EN 1176-1:2017, price on quotation.

The Double Eight develops our looped-tunnel concept into twin conjoined loops of curved steel, carrying two distinct rope tunnels – one suspended between the loops, one anchored at ground level. Seats, ladders, an acoustic telephone and three sensory panels round out a module that mixes climbing, balance and sensory exploration along an 11.3 m line.

Two tunnels, twice the exploration

The suspended tunnel, fitted with rubber mats, challenges children aged 5 to 14 to crawl and balance at height; the ground-anchored tunnel offers a sheltered passage for quieter exploration below. Between and around the loops, four ladders and two seats create circulation and rest points, while the acoustic telephone and three sensory panels add communication games and tactile discovery – features that extend the module’s appeal to children who engage through senses rather than strength.

Key features

• Two structural loops in curved steel tube, diameter 139.7 mm, on 114.3 mm posts
• Suspended rope tunnel with rubber mats plus ground-anchored second tunnel
• Two seats and four ladders
• Acoustic telephone and three sensory panels
• Hot-dip galvanised and powder-coated steelwork
• 18 mm braided polyamide rope reinforced with galvanised steel strands
• Free fall height 3.0 m; C20/25 concrete foundations at 1.0 m; minimum space 14.9 x 7.5 m

Specifications

Frequently asked questions

How does the Double Eight differ from the single Eight module?

It doubles the loop geometry to create two tunnels with different characters – one aerial, one grounded – and adds sensory equipment: acoustic telephone, sensory panels, extra seats and ladders.

What is the acoustic telephone?

A voice tube linking two points of the structure: children speak at one end and are heard at the other, encouraging cooperative and communicative play.

What area does it need?

A 14.9 x 7.5 m safety zone with surfacing rated for the 3.0 m free fall height; the slim 4.4 m width suits linear plots.

Request your quotation
