VIL 1 - Compact Tubular Climbing Frame with Stainless Steel Slide
VIL 1 - Compact Tubular Climbing Frame with Stainless Steel Slide : tubular play structures with rope climbing elements, marque Light In Fitness, tarif sur devis. VIL 1 – Structure tubulaire à grimper avec tobogganLa VIL 1 propose un parcours de grimpe ludique et compact, idéal pour les aires de jeux de taille moyenne. Livraison et installation chiffrées sur devis en France, en Belgique et en Suisse.
Price on request
Price on request – contact our team for a tailored project quotation.
Compact tubular climbing structure combining climbing ropes, a suspended nest seat and a stainless steel tube slide, ideal for medium-sized playgrounds.
This item is supplied on quotation: configuration, delivery and installation are priced against your project.
Request a quotation +33 6 20 72 66 96
Answer within 24 to 72 business hours, quote reference LIF-VIL1-1418. Layout study, delivery, installation and after sales.
Priced quotation within 24 business hours. No commitment. Our commitments
Description
Not every site has room for a monumental rope landscape – and that is exactly where the VIL 1 comes in. On a footprint of roughly 12.6 x 12.4 m, it packs climbing ropes, rope nets, a suspended nest seat and a stainless steel tube slide into a single coherent play circuit for children aged 5 to 14.
A complete climbing circuit on a medium footprint
The VIL 1 is designed as a loop: children climb the ropes, cross the netted sections, rest in the nest seat and exit down the slide. The tight-mesh zone (120 x 120 mm) offers an easier climbing surface for less confident users, while the main nets challenge older children – so one module serves the whole age band.
- 5 climbing ropes fitted with 240 mm platforms
- Nest-type suspended seat, 950 mm in diameter
- Stainless steel tube slide
- Tight-mesh climbing zone (120 x 120 mm)
- 4 rubber mats, 8 mm thick, reinforced with polyamide netting
- Free fall height: 3.0 m – minimum safety zone 17.5 x 16.6 m
Engineered for years of public use
The main frame uses steel tube with a diameter of 168.3 mm, protected by hot-dip galvanising. Nets are made of 18 mm polyamide rope reinforced with galvanised steel strands (average mesh 350 x 350 mm), assembled with polyamide connectors, aluminium components and stainless steel shackles and thimbles. The structure complies with EN 1176-1:2017 and is anchored on reinforced concrete footings set 1.0 m deep.
| Reference / SKU | LIF-VIL1-1418 |
|---|---|
| Dimensions (L x W x H) | 12.6 m x 12.4 m x 3.0 m |
| Frame | Steel tube, diameter 168.3 mm; 18 mm polyamide rope with galvanised steel strands |
| Finish | Hot-dip galvanised; stainless steel shackles and thimbles; stainless steel slide |
| Standard | EN 1176-1:2017 |
| Price | On request – project quotation within 24 business hours |
Frequently asked questions
Why a stainless steel slide rather than plastic?
Stainless steel tube slides resist UV fading, vandalism and temperature cycling far better than polyester slides, which matters on unsupervised public playgrounds with high daily traffic.
What total area should I plan for?
Beyond the 12.6 x 12.4 m structure itself, allow a minimum safety zone of 17.5 x 16.6 m with impact-attenuating surfacing rated for a 3.0 m free fall height.
Can the VIL 1 be combined with other modules?
Yes – it belongs to the same tubular family as the larger VIL 3 and Shaula structures, so a park can be developed progressively with a consistent visual identity.
Tell us about your playground project and receive a complete quotation – equipment, foundations and installation – within 24 business hours.
