Lexco LS-516 Incline Press - Plate-Loaded Upper Chest Machine

The Lexco LS-516 is a plate-loaded incline press with a converging push angle, measuring 1,375 x 1,640 x 1,110 mm and weighing 125.5 kg. It targets the upper chest and comes with adjustable handle angle, start position and seat height. Professional price: 2,145 EUR excluding VAT.

Converging arms for upper chest work

The push angle converges as the arms travel, so the hands finish closer together than they start. That reproduces the natural arc of an incline press with dumbbells while keeping the load on a fixed frame, and it increases the contraction at the top of the movement – which is where a barbell incline press gives the least.

The handle angle is adjustable, so users can rotate the grip to bias the load between the clavicular head of the pectorals and the anterior deltoid, rather than being locked into a single wrist position.

Adjustment and loading

• Adjustable handle angle for muscle contraction bias
• Adjustable starting angle and starting position
• Ten-position spring-loaded start bar
• Height-adjustable seat
• Two integrated plate holders
• Multiple loading horns supplied
• Supplied dismountable for installation in existing rooms

Technical specifications

Who specifies it

Gyms, sports clubs, corporate facilities and hotels building a free-weight chest area. A plate-loaded incline press is generally the second chest machine on a floor, after a flat chest press: it covers the upper pectorals, which selectorised chest presses reach poorly, and it needs no cable maintenance.

Compare it with the rest of the Lexco plate-loaded range or with the wider chest press machine selection.

Delivery and installation

The machine ships dismountable and is assembled on site by our teams, so basement rooms and upper floors reachable only by a standard lift are not an obstacle. Confirm doorway widths and lift dimensions when you request the quotation and we will note the access route on the layout drawing. Plate-loaded equipment has no electrical requirement, so the only site preparation needed is a level floor with a build-up suited to dropped plates around the loading positions.

Frequently asked questions

Why is the starting position adjustable?

Because shoulder mobility varies widely. A fixed start forces short users into an over-stretched position and long-limbed users into a shortened one. The ten-position bar lets each user set a safe stretch before the first repetition.

What maintenance does it require?

Very little. There is no cable, no pulley and no stack – the wear items are the bearings, the pads and the paint. That is the practical argument for plate-loaded equipment on a busy floor.

Can it be installed in an existing room?

Yes. The machine is supplied dismountable, so it can be moved through standard doorways and assembled in place, which matters in basements and upper-floor rooms.

Light In Fitness supplies plate-loaded and free-weight equipment to clubs, hotels, sports facilities and public bodies across Europe. Send your room dimensions and we will return a quotation excluding VAT with a layout study.
