Iluminator Climbing Structure with Rope Funnel

Name: Iluminator - Tubular Climbing Structure with Rope Funnel
Brand: Light In Fitness
SKU: LIF-ILUMINATOR-1404

Iluminator - Tubular Climbing Structure with Rope Funnel

Iluminator - Tubular Climbing Structure with Rope Funnel : tubular play structures with rope climbing elements, marque Light In Fitness, tarif sur devis. Brand : Light In Fitness. Delivery and installation priced on quotation across Europe.

Price on request

Shipping quoted separately The shipping cost is confirmed before you approve the order.

Price on request – contact our team for a tailored quotation.

Square 11.6 m climbing structure with central rope funnel and vertical rope walls, accessible from all sides. EN 1176 compliant from age 3.

This item is supplied on quotation: configuration, delivery and installation are priced against your project.

Request a quotation +33 6 20 72 66 96

Answer within 24 working hours, quote reference LIF-ILUMINATOR-1404. Layout study, delivery, installation and after sales.

Conformity: equipment designed to EN 1176 (playground equipment); the Light In Fitness declaration of conformity for this reference is supplied on request with the quotation.

Warranty: specified in the quotation for each reference — details of our warranties.

Description

In brief — Iluminator – Tubular Climbing Structure with Rope Funnel: material steel, free fall height 3,0 m, age range 3 to 14 years, safety area 16,6 x 16,5 m, standards EN 1176-1:2017, price on quotation.

The Iluminator anchors a playground the way a fountain anchors a square: a balanced 11.6 x 11.6 m steel frame whose central rope funnel and vertical rope walls draw children in from all four sides. Certified from age 3, it is the natural centrepiece for a new or refurbished play area.

A central attraction with all-round access

Symmetry is the Iluminator’s strength. The square plan gives equal access from every direction, feeding climbers aged 3 to 14 towards the central funnel – the gravitational heart of the structure where nets converge and descend. Vertical rope walls and climbing ropes around the perimeter offer alternative challenges, so traffic distributes itself naturally and the module remains readable for supervising adults from any position.

Key features

Square tubular steel frame, diameter 139.7 mm, hot-dip galvanised
Central rope funnel as focal climbing feature
Vertical rope walls and climbing ropes around the perimeter
Braided polyamide rope reinforced with galvanised steel strands, 18 mm
Plastic, aluminium and stainless steel connectors
Anchoring on reinforced concrete footings, depth 1.0 m
Age range 3 to 14; free fall height 3.0 m; minimum space 16.6 x 16.5 m

Specifications

Reference / SKU	LIF-ILUMINATOR-1404
Dimensions	11.6 m (L) x 11.6 m (W) x 3.0 m (H)
Frame	Tubular steel, diameter 139.7 mm, hot-dip galvanised
Finish	Steel-reinforced polyamide nets; aluminium and stainless steel connectors
Standard	EN 1176-1:2017
Price	On request – project quotation within 24 business hours

Frequently asked questions

Why choose a symmetrical square layout?

Equal access from all sides prevents queueing at a single entry, spreads wear evenly across the nets and lets the structure serve as the visual centre of the playground.

Is the Iluminator suitable for young children?

Yes – certification covers ages 3 to 14. The outer walls offer low, achievable climbs while the central funnel rewards more confident users.

What surfacing does it require?

Impact-attenuating surfacing rated for the 3.0 m free fall height across the 16.6 x 16.5 m safety zone, per EN 1176.

Request your quotation

Give your playground a centre of gravity – quotation returned within 24 business hours. Request a quote or compare rope play sets.

Rope care

Rinse ropes with clean water; solvents damage the fibres. Check wear at friction points and the condition of connectors and splices twice a year. A visible steel core means the element must be replaced.

Fiche produit originale rédigée et publiée par Light In Fitness (Tours), mise à jour le 03/08/2026 — source : https://lightinfitness.com/en/product/iluminator-rope-funnel-structure/. Textes et photos protégés ; reproduction sans autorisation interdite.

Additional information

Brand	Light In Fitness

Delivery and installation

Shipping is quoted according to quantity and delivery address; the amount is stated before you confirm.

This equipment is fixed to the ground (anchoring or grouting depending on the surface); installation can be quoted with delivery or done by your team.
