C12 stainless steel street workout and calisthenics station

In brief — C12 stainless steel street workout and calisthenics station: dimensions 800 × 600 × 310 cm, standards EN 16630:2015-06, EN 1177, designed by Light In Fitness in Tours and manufactured in Europe (stainless steel with lifetime warranty), price 24,999.00 € excl. VAT.

The C12 stainless steel station is an open street workout and calisthenics cage measuring 800 by 600 by 310 cm, occupying 48 m2 and accommodating 32 users at once, 20 on the frame and 12 around it. Unlike a linear trail, it is accessible from all four sides, so a whole group trains simultaneously with each participant at a different station under one instructor. It carries 12 main stations, 12 additional stations and more than 30 stainless accessories as standard. Built entirely in marine grade 316 and 316L stainless steel and certified EN 16630:2015-06E with an EU declaration of conformity, it is the reference for seafront and saline environments. It is priced at 24 999 EUR excluding VAT, structure and installation included, delivery charged separately.

Technical specification

Safety area, surfacing and anchoring

Plan the plot from the safety area rather than from the frame. The structure occupies 48 m2 but the minimum safety area is 900 by 900 cm, 81 m2, and the ideal working area is 100 m2, which gives room for the 12 users positioned around the frame as well as the 20 on it. That surrounding space is not a comfort margin, it is what makes the four sided access usable by a full class.

The free fall height must be established for each station from the layout plan and instructions. It is not the overall structure height. Select the surfacing using the documented performance and installation conditions of the complete system. Foundations and surfacing are quoted separately; installation of the structure is included.

Material choice is what sets this station apart from a galvanised cage. Marine grade 316 and 316L stainless resists saline corrosion, so the station can be installed on a seafront promenade, at a coastal campsite or beside a pool with cleaning and inspections adapted to the site. The finish is polished stainless with no lacquer, and the IHS columns carry no visible fixing holes, which removes the water traps that shorten the life of a conventional bolted rig. Estimated service life is more than 20 years with maintenance according to the manual.

Frequently asked questions

How does the C12 differ from a linear street workout trail?

Access. A linear trail sends users along a route one after another, whereas the C12 is open on all four sides with 24 stations arranged around a compact, almost square frame. That is what allows 32 people to train at once, each on a different station, with a single instructor supervising the rotation.

Is it genuinely suitable for a seafront site?

Yes. The whole structure is marine grade 316 and 316L stainless, the grade specified for saline exposure, and the finish carries no coating that could fail. That is the reason it is priced above a galvanised equivalent and why cleaning, periodic inspections and wear-part checks must be included in the operating budget.

What does 24 999 EUR cover?

The structure with its 24 stations and more than 30 stainless accessories. Delivery, foundations and EN 1177 surfacing are quoted with the project; installation is included. Lead time is 30 to 90 days.
