LETO XL Rope Crossing with Arches
LETO XL Rope Crossing with Arches : rope play modules for playgrounds, marque Light In Fitness, tarif sur devis. Delivery and installation priced on quotation across Europe.
Price on request
Price on request — project quotation within 24 business hours.
Wide-span rope crossing with six half-circle arches and an adjustable main rope height.
This item is supplied on quotation: configuration, delivery and installation are priced against your project.
Request a quotation +33 6 20 72 66 96
Answer within 24 to 72 business hours, quote reference LIF-LETOXL-013. Layout study, delivery, installation and after sales.
Description
LETO XL carries six half-circle arches on a main rope spanning 4.24 m, with the rope height adjustable between 1.4 m and 2.85 m. The longer traverse and the closer succession of arches turn a short crossing into a sustained sequence.
Six arches instead of four
Adding two arches over an extra 1.24 m of span shortens the gap between hand supports. That sounds like it should make the crossing easier, and for a small child it does; for an older one it does the opposite, because the traverse now lasts long enough for grip fatigue to matter. The module therefore serves a wider age band than the standard version from a single installation.
- Main horizontal rope, height adjustable from 1.4 m to 2.85 m
- Six half-circle curved ropes, radius approximately 0.3 m
- Stainless steel articulated connections
- Aluminium and plastic connectors
Technical specification
| Reference | LIF-LETOXL-013 |
|---|---|
| Dimensions | 4.6 x 0.3 x 3.0 m (L x W x H) |
| Age range | 5 to 14 years |
| Free height of fall | 2.85 m |
| Safety area | 5.3 x 9.6 m minimum |
| Foundation depth | 1.0 m, reinforced concrete footings |
| Arches | Six half-circles, radius approximately 0.3 m |
| Main rope height | Adjustable, 1.4 m to 2.85 m |
| Post spacing | 4.24 m |
| Frame | Hot-dip galvanised steel posts, 168.3 mm diameter |
| Ropes | Braided and bonded polyamide, 18 mm, galvanised steel core |
| Standard | EN 1176-1:2017, certificate issued by an independent certification body |
| Price | On request — project quotation within 24 business hours |
Where the XL span pays off
On a school site with a single break period and two hundred pupils, the limiting factor is how many children can be on the equipment at once. A longer traverse with more supports absorbs more users per minute for an extra 1.3 m of surfaced length, which is the cheapest capacity available in the collection.
Installation and surfacing
Reinforced concrete footings at 1.0 m depth, heavy plant access required, and an impact attenuating surface to EN 1176-1 across the full 5.3 x 9.6 m safety area, sized against the 2.85 m free height of fall.
Frequently asked questions
Should the rope be set low or high?
It depends on the user group. Primary schools generally set it towards the lower end of the range; parks serving mixed ages set it higher. We discuss the setting before installation.
Can two children cross at the same time?
The longer span makes this physically possible, but the ropes interact when loaded at two points. Supervised settings normally run one child at a time.
Are the arches replaceable individually?
Yes. Each curved rope is a separate assembly connected through stainless steel articulated fittings and can be changed without dismantling the main rope.
Request a quotation with your available length, or see the other rope play modules.
