Play Configuration 47: Three Rope Towers with Funnel Net
Play Configuration 47: Three Rope Towers with Funnel Net : complex playground configurations with towers and slides, marque Light In Fitness, tarif sur devis. Configuration de jeu complexe 47Cette structure de jeu en corde pour aire de jeux extérieure réunit trois tours grimpantes reliées par un module central en filet en forme d'entonnoir. Delivery and installation priced on quotation across Europe.
Price on request
Price on request — project quotation within 24 business hours.
Rope play configuration of three SPICA climbing towers joined by a central funnel net module. Ages 5 to 14, EN 1176-1.
This item is supplied on quotation: configuration, delivery and installation are priced against your project.
Request a quotation +33 6 20 72 66 96
Answer within 24 to 72 business hours, quote reference LIF-CONF47-1147. Layout study, delivery, installation and after sales.
Description
Play configuration 47 brings together three SPICA rope climbing towers linked by a central funnel-shaped net module. The result is one continuous play volume of 15.1 x 14.8 m in which children move between towers without returning to the ground.
Three towers, one connected space
Each SPICA tower works as an independent climb, but the funnel module in the centre changes how the scheme is used. Children converge on it from three directions, and the funnel geometry concentrates them into a shared space before they fan out again. That rhythm — disperse, converge, disperse — is what distinguishes the configuration from three towers placed side by side.
Components and construction
- Three SPICA rope climbing towers.
- One central suspended funnel net module linking all three.
- Steel structure, hot-dip galvanised and powder-coated.
- Braided polyamide rope, 18 mm diameter.
- Aluminium and stainless steel connectors; concrete pad foundations at 0.8 m depth.
Siting and surfacing
The configuration measures 15.1 x 14.8 x 4.1 m and requires a minimum safety area of 18.9 x 18.2 m. Free height of fall is 2.0 m — lower than the taller rope towers in the range, which eases the surfacing specification. The equipment is certified to EN 1176-1:2017-12 with a certificate of conformity from an independent certification body. Impact-attenuating surfacing is a separate matter, tested to EN 1177 and rated for a critical fall height of at least 2.0 m across the full safety area.
Technical specification
| Reference / SKU | LIF-CONF47-1147 |
|---|---|
| Dimensions (L x W x H) | 15.1 x 14.8 x 4.1 m |
| Age range | 5 to 14 years |
| Free height of fall | 2.0 m |
| Safety area | 18.9 x 18.2 m minimum |
| Frame | Hot-dip galvanised steel, powder-coated |
| Finish | 18 mm braided polyamide rope; aluminium and stainless steel connectors |
| Foundations | Concrete pads, 0.8 m depth |
| Standard | EN 1176-1:2017-12, certificate of conformity from an independent body |
| Price | On request — project quotation within 24 business hours |
Frequently asked questions
Why are the foundations shallower than on other rope structures?
Pad depth follows the loads and the overturning moment of each tower. At 4.1 m overall height with three mutually braced towers, 0.8 m pads are sufficient. The foundation design is issued with the siting drawing and should be checked against your ground conditions.
Can two towers be specified instead of three?
The funnel module is designed to meet three towers. A two-tower scheme is a different configuration and would be quoted with its own certification file.
Is the central net accessible to less confident climbers?
The funnel is reached from each tower at mid-height rather than at the top, so it does not require a full climb. It is also the point where a supervising adult has the clearest view of all three towers at once.
Request a quotation. Send your site plan and we will return a project quotation, siting drawing and foundation design within 24 business hours.
